M3SR Series 4100 Overview

3.2 Operating Manual 6175.4760.02 – 01

Figure 3.2 Radio Backplane with Interfaces

1 Audio/Line Connector

2 Serial Connector (RS-232-C, Data)

3 Serial Connector (RS-232-C, Remote Control)

4 LAN Connector

If connected to a LAN, all functions of the radio can be remotely configured and controlled

for example with the R&S GB4000C Control Unit.

ICN-4D-C-231000-R-D0894-00021-A-01-1

1

2

3

4
