M3SR Series 4100 Menu Radio MTC 3/7 (3003)
3.82 Operating Manual 6175.4760.02 – 01
3.4.8 Menu Radio MTC 3/7 (3003)
Figure 3.45 Menu 3003: Radio MTC 3/7 3003
In the central area of the menu Radio MTC 3/7 the settings of the serial interface (parameters
of serial data connector on the radio backplane, e.g. baudrate, flow control, data parameters,
data and DCD mode) and the selected operation mode of the digital selective calling module
(DSC, option) are displayed.
Table 3.21 Softkeys in Menu Radio MTC 3/7 (3003)
Softkey Description Possible Values
Navigate to the previous menu (Radio MTC 2/7, see
sect. 3.4.5 Menu Radio MTC 2/7 (3002)).
ICN-4D-J-231000-R-D0894-00055-A-01-1
