Operating Manual 6175.4760.02 – 01 2.5
M3SR Series 4100 Installation and Removal
1 Fixing at rack at the front-side
2 The maximum screw-in depth is 3.5 mm
3 8 x Phillips screws M4 x 6 (Ident. no.: 0396.8181.00)
8 x washers (Ident. no.: 0005.0315.00)
4 Telescopic slide (Ident. no.: 0657.5807.00 (6105.9263.00))
5 Extension of the telescopic slide: 377.7 mm (530.1 mm)
6 Side length: 457.2 mm (508 mm)
The telescopic slides are available on demand (Ident. no. 0657.5807.00, only for racks
provided for a fixed depth of 600 mm and accessible from the rear, or 6105.9263.00 for
trailing cable installation).
The load capacity for the telescopic slides is 380 N.
Removal
Remove radio in reverse order of installing it.
