Operating
Manual 6175.47
60.02
–
01
4.119
M3SR Series 4100
Changing ALM Interval for Data Links
4.4.5.28
Changing ALM Inter
val for Data Links
Softkey
Type
Description
Editor
1.
Press softkey 'Intvl Data'.
2.
Enter desired interval.
3.
Press 'ENT' to confirm.
Possible values:
0 to 1440
454
