Operating Manual 6175.4760.02 – 01 4.65
M3SR Series 4100 Common ALE-2G and ALE-3G FF and HF Modem Menus
4.3.7.2 ALE-2G/ALE-3G HF Modem Operational and Configuration Menus
Below, the HF modem menus with their operational and configuration softkeys are shown -
when used together with ALE-2G or ALE-3G. For detailed description of the softkeys, please
see sect. 4.5.3 HF Modem Operational Menu and sect. 4.5.4 HF Modem Configuration
Menu.
Figure 4.13 Menu 1511: HFM OP 1/1 (ALE-2G)
In contrast to normal HF Modem operation the central area shows the ALE status (2G
or 3G) for easy monitoring of ALE events.
ICN-4D-H-231072-R-D0894-00013-A-01-1
