Operating Manual 6175.4760.02 – 01 3.25

M3SR Series 4100 Operating Concept

Table 3.11 Domains and Parameters

3.2.2.7 Menu Tree

As all the operation is menu-based, the menu tree gives an overview of all the menus avail-

able to operate the radio and the CU.

The menu tree shows where to find a particular menu.

Domain Description

Communication

Mode

Operation This domain contains the parameters of the active communication

mode which are essential to operate the radio in this communication

mode.

Configuration This domain mainly contains the parameters to (pre)configure the ac-

tive communication mode.

Fillgun In the menu of this domain the download of a radio configuration via fill-

gun can be controlled (see sect. 3.3 Control and Monitoring of Radio

and Control Unit).

Radio maintenance This domain contains all settings of the radio independent of the com-

munication mode (for details see sect. 3.4 Radio Maintenance).

CU maintenance This domain offers all parameters concerning the CU only (for details

see sect. 3.5 Control Unit Maintenance).
