M3SR Series 4100 Radio Configuration with Pre-configured Parameters
3.184 Operating Manual 6175.4760.02 – 01
Figure 3.75 Available Preset Page after Delivery from Factory
Additionally up to 99 customized so called Preset Pages (presets) can be loaded to the radio.
To each Preset Page a communication mode with a complete set of parameters for this com-
munication mode is assigned. The possible communication modes are:
• Fixed Frequency (FF)
• Automatic Linking Establishment (ALE-2G and ALE-3G, option)
• R&S SECOM-H (option)
• HF Modem (option)
The communication mode FF is available on each radio. ALE, SECOM-H and HF Modem
are options.
All presets are easily prepared with a PC, using the Radio Network Management System
(R&S RNMS3000, for details see R&S RNMS3000 documentation).
ICN-4D-G-231000-R-D0894-00101-A-01-1
