M3SR Series 4100 Switching the Radio Off
2.30 Operating Manual 6175.4760.02 – 01
2.7 Switching the Radio Off
Figure 2.12 Switching the Radio Off
1 Radio Button ON / OFF
2 Radio LED AC / DC
3 Radio LED BATT (Battery)
4 Radio LED GO
ICN-4D-C-231000-R-D0894-00015-A-01-1
1 2
3
4
