Operating Manual 6175.4760.02 – 01 1.5
M3SR Series 4100 User Information
1.4 Design
All radios consist of the following modules:
• Front Panel
• Motherboard
• R&S IN4400A AC/DC Power Supply (Receiver)
• Power Supply (Receiver / Exciter)
• Power Amplifier (Transceiver)
• PMU Unit (Power Management Unit)
• Frontend
•Synthesizer
• Radio Controller
• Interface Module
• Antenna Interface
• Additional internal hardware options
- R&S FK4120 20 dB Digital Selector
- R&S FK4140 40 dB Digital Selector
- R&S GB4000C Comfort Control Unit
- R&S GS4102 NMEA Interface
• Software options (see Table 1.1)
