R&S M3SR 4100 Series User Manual

M3SR Series 4100 Recalling Settings
3.136 Operating Manual 6175.4760.02 – 01
3.7.2.2 Recalling Settings
Softkey Softkey Type Description
Editor 1. Press 'Channel Recall' softkey.
2. Enter desired channel.
3. Press 'ENT 'key to confirm.
If the 'Channel Recall' softkey is pressed, it
shows the frequency and modulation of the
channel.
Channel not used (e.g.)
Channel used (e.g.)
The channel is recalled automatically after the
time set via softkey 'Ch. Auto Recall Time'
(see sect. 3.5 Control Unit Maintenance)
The 'Channel Recall' softkey is used to recall
settings stored with the 'Channel Store' func-
tion (see sect. 3.7.3.1 Storing Current Set-
tings) or with the R&S RMNS3000 or to recall
the predefined fix maritime channels. The ef-
fective channel is displayed in the menu head-
er, e.g. CH: 101. Channels from 1 to 400 are
pre-configured with the R&S RNMS3000 soft-
ware tool and can be configured as modifiable
or not. If a channel is not modifiable, the user
will not be able to edit its parameters from the
MMI.. Channels between 401 and 25040 are
pre-defined maritime channels. For the mari-
time channels the radio is able to distinguish
between ship or shore configuration, where Rx
and Tx frequencies are swapped. See also
sect. 3.7.4.5 Switching Environment Shore or
Ship.
