M3SR Series 4100 Selecting the xDL Mode

Table 4.4 Dependency of Packet Size on Selected Traffic Mode

Traffic Mode Packet Size / Payload

LDL 32 32 bytes

LDL 64 64 bytes

LDL 96 96 bytes

LDL 128 128 bytes

LDL 160 160 bytes

LDL 192 192 bytes

LDL 224 224 bytes

LDL 256 256 bytes

LDL 288 288 bytes

LDL 320 320 bytes

LDL 352 352 bytes

LDL 384 384 bytes

LDL 416 416 bytes

LDL 448 448 bytes

LDL 480 480 bytes

LDL 512 512 bytes

HDL 3 699 bytes

HDL 6 1398 bytes

HDL 12 2796 bytes

HDL 24 5592 bytes
