R&S M3SR 4100 Series - Figure 5.4 Own GPS Position

Operating Manual 6175.4760.02 – 01 5.19
M3SR Series 4100 Display of the GPS Position
Figure 5.4 Own GPS Position
1Time
GPS time in HH-MM-SS.
2 Date
GPS date in CCYY-MM-DD.
3 Velocity
Current velocity in forward direction - Velocity in km/h.
4 Satellites
Current GPS reception quality - Number of satellites received (1 to 10) or ‘---’ for no satellites.
5 Alt. (Altitude)
In meter from sea level.
6 Zone
UTM zone indication.
7 Pos. (Position)
Latitude - In degrees and milliminutes plus north / south indication.
Longitude - In degrees and milliminutes plus east / west indication.
ICN-4D-H-231052-R-D0894-00003-A-01-1
1
2
3
4
5
6
7
