M3SR Series 4100
Changing ALM Inter
val for LLE
4.118
Oper
ating
Manual 6175.4760
.02
–
01
4.4.5.27
Ch
anging ALM
Interval f
or LLE
Softkey
Type
Description
Editor
1.
Press softkey 'LLE Intvl'.
2.
Enter desired interval.
3.
Press 'ENT' to confirm.
Possible values:
0 to 1440
