M3SR Series 4100 Radio Maintenance
3.48 Operating Manual 6175.4760.02 – 01
3.4 Radio Maintenance
For more information refer to sect. 9 Drawings: Menu Structure
This domain contains all parameters and settings of the radio which are independent of a
communication mode.
To navigate to the radio maintenance submenus it is required that the control unit is connect-
ed to the radio (see sect. 3.3 Control and Monitoring of Radio and Control Unit).
The radio maintenance domain has 7 submenus in the domain root and three subdomains.
Each of the subdomains ('Radio Error', 'Radio Inventory' and 'Split Site') has two submenus.
From the Home menu navigate to the first radio maintenance menu (see sect. 3.3 Control
and Monitoring of Radio and Control Unit). From the first radio maintenance menu navigate
to the subdomains. The fourth radio maintenance menu has three folders. The structure of
the radio maintenance menu domain is shown in Figure 3.30.
