M3SR Series 4100 Rebroadcast / Relay Mode
5.62 Operating Manual 6175.4760.02 – 01
Relay Mode
The Relay Mode is mainly used to extend the operating range of radios within one IP subnet/
waveform net. A typical scenario could be if the radios are located around a hill, so that some
radios cannot catch the radio signals from the others. The Relay Station, placed at the top of
the hill, can be "seen" and reached by all radios around. A Relay Station consists of two ra-
dios which are connected "back-to-back" over their local Ethernet using a Rohde & Schwarz
accessory cable (ord. no. R&S GK3022 6148.6595.02).
In order to realize a relay scenario it is also necessary to configure the waveform net accord-
ingly.
