M3SR Series 4100 HF Modem Menu Tree

4.124 Operating Manual 6175.4760.02 – 01

4.5.1.1 HF Modem Menu Tree

The menu tree gives an overview of all the menus available for HF Modem operation and

configuration. The menu tree shows how to reach the HF Modem Operation, the Configura-

tion and the Service menu.

Figure 4.24 Menu Tree: HF Modem

HF Modem Home

1511

HFM OP 1/1

1521

HFM CFG 1/1

1551

GPS OP

ICN-4D-H-231063-R-D0894-00002-A-01-1
