M3SR Series 4100 Required Power Supply for Receiver / Exciter or PMU
1.12 Operating Manual 6175.4760.02 – 01
Table 1.2 Available Power Supply Models
Type designation Order no. Model Supply V
in
Frequency (Hz)
R&S IN4150 6120.0705.02 02 1/3PH (+n) 230 V AC (1PH)+10/-15% 47 to 63
208 V AC ()+10/-15% 47 to 63
230 V AC (Y)+10/-15% 47 to 63
R&S IN4190 6120.2708.02 02 1/3PH (+n) 230 V AC (1PH)+10/-15% 47 to 63
208 V AC ()+10/-15% 47 to 63
230 V AC (Y)+10/-15% 47 to 63
115 V AC (1PH)+/-20% 47 to 63
R&S IN4150 6120.0705.12 12 DC 220 V DC -
R&S IN4190 6120.2708.12 12 DC 220 V DC -
R&S IN4150 6120.0705.03 03 3PH 440 V AC ()+/-20% 47 to 63
R&S IN4190 6120.2708.03 03 3PH 440 V AC ()+/-20% 47 to 63
