Operating Manual 6175.4760.02 – 01 3.97
M3SR Series 4100 Control Unit Maintenance
3.5 Control Unit Maintenance
For more information refer to sect. 9 Drawings: Menu Structure
The control unit maintenance domain contains all parameters and settings of the control unit.
The control unit maintenance domain has four submenus in the domain root and three sub-
domains. The subdomains 'Control Unit Error' and 'Control Unit Inventory' have two sub-
menus and the subdomain 'Keyboard Test' has one submenu. From the Home menu
navigate to the first control unit maintenance menu (see sect. 3.3 Control and Monitoring of
Radio and Control Unit). From the first control unit maintenance menu navigate to the sub-
domains. The structure of the control unit maintenance menu domain is shown in
Figure 3.54.
