R&S M3SR 4100 Series User Manual

Operating Manual 6175.4760.02 – 01 4.99
M3SR Series 4100 Selecting the LDL Number of Bytes per Tx Frame
4.4.5.9 Selecting the LDL Number of Bytes per Tx Frame
Softkey Selection / Editor Description
Listbox 1. Press 'LDL Byte' softkey.
2. Select desired number of bytes from list-
box.
3. Press 'ENT' to confirm.
Possible values (in bytes):
32 – 64 - 96 – 128 – 160 – 192 – 224 – 256 –
288 – 320 – 352 – 364 – 416 – 448 – 480 – 512
