M3SR Series 4100
Changing ALM Interval for Voic
e Links
4.116
Oper
ating
Manual 6175.4760
.02
–
01
4.4.5.25
Changing ALM In
terval for Voice Links
Softkey
Type
Description
Editor
1.
Press softkey 'Intvl Voice'.
2.
Enter desired interval.
3.
Press 'ENT' to confirm.
Possible values:
0 to 1440
451
453
