M3SR Series 4100 System Cabling for Transceiver
2.20 Operating Manual 6175.4760.02 – 01
Figure 2.8 System Cabling for Transceiver
1 Mains Connection
2 Ground Connection
3 Ground Connection (M6)
4 DC cable (R&S IN4000A Power Supply – R&S XK4115), for instance R&S GK4103,
6120.5807.xx ( xx: 05 = 0.5 m, 10 = 1.0 m, 25 = 2.5 m)
5 Antenna Tuning Unit Connection (Control)
6 Battery Connection
7 Antenna or Antenna Tuning Unit Connection (RF), Type N
1
2
3
4
5
6
7
ICN-4D-F-231000-R-D0894-00136-A-01-1
