Operating Manual 6175.4760.02 – 01 2.3
M3SR Series 4100 Installation and Removal
2.2 Installation and Removal
Refer to (sect. 9 Drawings: Interface Description).
Installation
For installation (see Figure 2.1) into a 19" rack with telescopic slides proceed as follows:
1. Take the right-hand telescopic slide and extend it as far as possible.
2. Press the automatic unlocking device and pull the innermost slide completely out.
3. Attach the innermost slide to the right-hand side panel of the radio with four Phillips
screws and the associated washers.
4. Take the left-hand telescopic slide and extend it as far as possible.
5. Press the automatic unlocking device and pull the innermost slide completely out.
6. Attach the innermost slide to the left-hand side panel of the radio with four Phillips screws
and the associated washers.
7. Take the outer telescopic slides and mount them to the rack.
8. Insert the radio, with its slides fitted, into the extended slides of the rack and slide it in
until the stop is reached.
9. Fasten the radio to the rack using four screws.
