M3SR Series 4100 Selecting the Data Rate for SECOM-H Transmission
4.188 Operating Manual 6175.4760.02 – 01
Table 4.8 Dependency of Waveform/Air Data Rates on Data Rates/Modes of Data Term 1
Transmission mode for
RS232 (DT1)
Selected data rate for
RS232 (DT1)
Possible waveforms Possible air data rates
Synchronous 2400 bit/s WF5
Synchronous 1200 bit/s WF5 1200 bit/s (fix)
WF2 1200 bit/s (fix)
Asynchronous > 2400 bit/s WF5 2400 bit/s
1200 bit/s
WF3 1200 bit/s
WF2 1200 bit/s
600 bit/s
300 bit/s
WF1 600 bit/s
300 bit/s
150 bit/s
75 bit/s
Asynchronous 2400 bit/s WF5 1200 bit/s
WF3 1200 bit/s
WF2 1200 bit/s
600 bit/s
300 bit/s
WF1 600 bit/s
300 bit/s
150 bit/s
75 bit/s
Asynchronous 1200 bit/s WF2 600 bit/s
300 bit/s
WF1 600 bit/s
300 bit/s
150 bit/s
75 bit/s
