M3SR Series 4100 ALE 2G Configuration Menus
4.34 Operating Manual 6175.4760.02 – 01
4.3.6 ALE 2G Configuration Menus
The ALE-2G configuration menu consists of three different pages. While the first two pages
are focused on address definition, AMDs, link quality analysis / sounding, ATU bypass, tim-
ings and user unique functions, the last page is dedicated for ALE-2G linking protection. The
Linking Protection menu (page 1223) is explained separately.
Menu Structure of Configuration Menus
In the central area of the configuration menus the currently set configuration parameters are
displayed.
Figure 4.7 Menu 1221: ALE CFG 1/3 (ALE-2G)
1. Listen before Transmit
2. Response Timeout
3. Default Link Mode Voice
1
2
3
ICN-4D-G-231072-R-D0894-00007-A-01-1
