R&S M3SR 4100 Series - Figure 3.76 Loading Configuration to Radio Via Serial Cable

Operating Manual 6175.4760.02 – 01 3.187
M3SR Series 4100 Download from PC into Radio via Serial Cable
Figure 3.76 Loading Configuration to Radio via Serial Cable
1PC
2 Serial Cable
3Radio
ICN-4D-C-231000-R-D0894-00086-A-01-1
2
3
1
