Operating Manual 6175.4760.02 – 01 3.115
M3SR Series 4100 Control Unit MTC 3/4 (4003)
Figure 3.63 Listbox Connect to Radio
In the example below (see Figure 3.64) the same two radios are listed as in the previous ex-
ample, but radio 1 with the logical address 11 is specified as local. (This means that the con-
trol unit is built into the radio with logical address 11 and radio IP address 192.168.52.34.)
ICN-4D-C-231000-R-D0894-00070-A-01-1
