M3SR Series 4100 Synthesizer Calibration
7.6 Operating Manual 6175.4760.02 – 01
Figure 7.4 Radio Maintenance Menu, Calibration Possible
7. Start the calibration by pressing 'Start SYN CAL' in the Radio Maintenance menu.
During an ongoing calibration do not switch off the radio or disconnect the antenna. The process takes
1 to 2 minutes, indicated by message 'Calibration running' (see Figure 7.5).
ICN-4D-G-231000-R-D0894-00130-A-01-1
