M3SR Series 4100 Download via LAN
3.198 Operating Manual 6175.4760.02 – 01
The following steps are required to download the configuration:
1. Connect radio back plane LAN connector and PC to LAN (see Figure 3.81) and make
sure that both are in the same IP subnet.
2. Switch PC and radio on (make sure that the radio is on Preset Page 0).
3. Start the R&S RNMS3000 Mission Planner (MPlan) on the PC. For further information
refer to R&S RNMS3000 documentation.
4. Create a new mission with the R&S RNMS3000.
5. Generate the radio configuration with the R&S RNMS3000.
6. Start the R&S RNMS3000 Remote Device and Loader (RDL) software. For further infor-
mation refer to R&S RNMS3000 documentation.
7. In RDL switch to the tab "LAN M3TR/S4100".
8. Search for available radios in the LAN using the popup menu item "Search in LAN". All
available radios are displayed after a short time. If no radios are found check the IP set-
tings of the PC and the radio.
9. Select the desired radio configurations in the left window of RDL.
10. Copy the configurations to the desired radio using drag and drop.
11. Exit RDL software.
12. Disconnect radio and PC from LAN.
For download via LAN monitoring as well as operational access rights are required. If
the access rights are not available (e.g. 3 CUs with monitoring sessions are connected
or 1 CU with Fixed or Local session is connected), the download will fail.
If a successful download has been finished, the radio automatically reboots if the radio IP
address has been changed due to the new configuration. In this case a new connect of the
control unit to the radio with the new IP address is required (see sect. 3.3 Control and Mon-
itoring of Radio and Control Unit and sect. 3.5.3 Control Unit MTC 3/4 (4003))
