ERROR CODE and TROUBLESHOOTING
8 - 307
8.5.8 Blurred image
Fig.8-16
Cause/Section Step Check item Measures
Scanner 1 Is the scanner bedewed? Clean it.
Drum 2 Is the drum bedewed or dirty? Wipe the drum with dry cloth.
Be sure never use alcohol or other
organic solvents because they have
bad effect on the drum.
Ozone exhaust 3 Is the ozone exhaust fan operating
properly?
Check the connection of the
connector.
4 Is the ozone filter stained or
damaged?
Replace it.
Main charger 5 Check if the inside wall in the case of
the main charger unit is dirty or there
is any fouling in the case of the main
charger unit.
Clean the inside wall in the case.
6 Check if the main charger grid is
corroded, or rusted, or there is any
fouling on the grid.
Replace the main charger grid.
To Next Page
