e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved
SELF-DIAGNOSTIC MODE
5 - 60
5.15 Default setting / restore setting of the EFI Printer Board
The codes whose value can be changed by performing “Default setting of the EFI Printer Board (08-
9951)” or “Restore setting of the EFI Printer Board (08-9952)” are listed below.
Setting mode (08)
Code Item
Default value
when 08-9951 is
performed
Default value
when 08-9952 is
performed
08-3754 Switching DPWS printer setting 2 1
08-3755 Switching DPWS Scanner setting 2 1
08-3767 Switching IPv6 setting 2 2
08-4131 Feeding retry setting 1 0
08-4621 Bypass feed paper size detection setting 1 0
08-4675 Paper ejection setting for wrong bypass paper
size
02
08-8735 Sending setting of ScanToURL 0 0
08-8800 Enabling / Disabling of 802.1X 2 2
08-8802 Enabling / Disabling of IPsec 2 2
08-8804 Enabling / Disabling of IP filtering 2 2
08-8805 Enabling / Disabling of MAC address filtering 2 2
08-8904 Enabling / Disabling of job jump instruction setting 0 0
08-8915 Enabling / Disabling of automatic output of jobs at
login
00
08-8967 Rotation printing by guides width of bypass feed
tray
01
08-9236 Default setting of print screen 2 1
08-9406 Address Mode 1 2
08-9408 IP address 10.250.250.249 0.0.0.0
08-9409 Subnet mask 255.255.255.252 0.0.0.0
08-9410 Gateway 10.250.250.250 0.0.0.0
08-9411 Availability of IPX 2 2
08-9414 Availability of AppleTalk 2 2
08-9473 Availability of Raw/TCP 2 1
08-9475 Availability of LPD client 2 1
08-9478 Availability of IPP 2 1
08-9489 Availability of FTP print 2 1
08-9505 Bonjour setting 2 1
08-9599 Samba server ON/OFF setting 2 1
08-9709 Default data saving directory of “Scan to File” 0 0
To Next Page
