e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved
PREVENTIVE MAINTENANCE (PM)
7 - 74
7.9 PM KIT
A PM kit is a package for each unit of replacement parts requiring PM
*1:
Part list <P-I> represent
s
the page item
in “e-STUDIO5540C/6540C/6
550C, e-STUDIO5560C/
6560C/6570C Service Parts List”.
*2: The following seal is attached to the 2nd transfer roller cleaning blade.
KIT name Component Qty.
Parts list
<P-I>
*1
EPU-KIT-FC65-G
Needle electrode 1
64-13
Main charger grid 1
64-17A
Needle electrode cleaner 1
64-16
Drum cleaning blade 1
63-21
EPU-KIT-FC65-S
(For e-STUDIO6550C: K)
Needle electrode 1
64-13
Main charger grid 1
64-17B
Needle electrode cleaner 1
64-16
Drum cleaning blade 1
63-21
TBU-KIT-FC65
2nd transfer facing roller cleaning pad 1
30-51
Transfer belt cleaning blade 1
34-1
Transfer belt cleaner side seal (front) 1
34-18
Transfer belt cleaner side seal (rear) 1
34-22
TR2-KIT-FC65
2nd transfer roller 1
29-31
2nd transfer roller cleaning blade
*2
1
29-24
2nd transfer Lubricant unit 1
29-9
FLTR-KIT-FC55
Toner filter 1 49-11
Ozone filter 1 1
49-4
Ozone filter 2 1
49-14
FLTR-KIT-FC65
Toner filter 1 49-11
Ozone filter 1 1
49-4
Ozone filter 2 1
49-14
VOC filter 1 1 1-107
VOC filter 2 1 2-111
FR-KIT-FC55
Fuser roller 1
43-17
Fuser belt 1
43-16
Pressure roller 1 42-1
Pressure roller separation finger 5
41-3
Fuser belt guide 2
43-18
ROL-KIT-81CST
Pickup roller 1
11-36
Feed roller 1
11-36
Separation roller 1
11-35
DF-KIT-3018 Pickup roller 1 81-12
Feed roller 1 81-12
Separation roller 1 82-8
ROL-KIT-4004 Pickup roller 2 5-46
Feed roller 2 4-2
Separation roller 2 4-3
Part Qty. P - I
2nd transfer roller side seal 1 29-34
To Next Page
