e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved
OUTLINE OF THE MACHINE
3 - 28
3.3 Symbols and Functions of Various Components
The column “P-I” shows the page and item number in the parts list.
3.3.1 Motors
Symbol Name Function Remarks P-I
MR1 Original feed motor Driving the original feed roller, pickup
roller and registration roller
Fig. 3-4 87-14
MR2 Read motor Transporting originals by driving the
intermediate transport roller, front read
roller, rear read roller and reverse
registration roller
Fig. 3-4 87-7
MR3 Original reverse motor Driving the original reverse roller Fig. 3-4 87-28
MR4 Original exit motor Driving the original exit roller Fig. 3-4 87-9
M1 Scan motor Driving the carriages Fig. 3-5 51-9
M2 Exit motor Driving the exit roller Fig. 3-5 37-6
M3 Reverse motor Driving the reverse section Fig. 3-6 23-36
M4 Bridge unit transport entrance motor Driving the entrance transport roller of
the bridge unit
Fig. 3-6 23-36
M5 Bridge unit transport exit motor Driving the bridge unit exit transport
roller of the bridge unit
Fig. 3-6 23-36
M6 Fuser motor Driving the fuser Fig. 3-7 39-42
M7 ADU motor-1 Driving the automatic duplexing unit Fig. 3-16 18-2
M8 ADU motor-2 Driving the automatic duplexing unit Fig. 3-16 18-2
M10 TRU waste toner motor Flat (horizontal) transporting waste
toner in the TRU
Fig. 3-13 21-13
M11 TRU waste toner transport motor Vertical transporting waste toner in the
TRU
Fig. 3-13 27-55
M12 Bypass motor Feeding/transporting paper in bypass
unit
Fig. 3-18 15-77
M13 Transfer belt motor Driving the transfer belt Fig. 3-12 32-23
M14 Transfer belt cam motor Driving the contact/release movement
of the transfer belt
Fig. 3-12 32-18
M15 Toner motor-K Toner supply from the K toner cartridge
to the K sub-hopper
Fig. 3-15 45-8
M16 Toner motor-C Toner supply from the C toner cartridge
to the C sub-hopper
Fig. 3-15 45-9
M17 Toner motor-M Toner supply from the M toner cartridge
to the M sub-hopper
Fig. 3-15 45-9
M18 Toner motor-Y Toner supply from the Y toner cartridge
to the Y sub-hopper
Fig. 3-15 45-9
M19 Sub-hopper toner motor-K Normal rotation:
Toner supply from the K sub-hopper to
the K developer unit and mixing toner
in the K sub-hopper
Reverse rotation:
Mixing toner in the K sub-hopper
Fig. 3-11 60-13
M20 Sub-hopper toner motor-C Normal rotation:
Toner supply from the C sub-hopper to
the C developer unit and mixing toner
in the C sub-hopper
Reverse rotation:
Mixing toner in the C sub-hopper
Fig. 3-11 60-13
To Next Page
