SETTING ADJUSTMENT
6 - 33
6.2.2 Density adjustment
The center density and the density variation controlled by density adjustment keys can be adjusted as
follows.
<Adjustment Mode (05)>
*1: If Text/Photo is set in the mono color, the density levels of “Image smoothing” in the black mode will
be affected.
*2: If Printed Image is set in the mono color, the density levels of “Photo” in the black mode will be
affected.
<Adjustment Mode (05)>
Make a test copy and compare the image obtained with the current settings; if necessary, make
adjustments according to the following procedure.
Notes:
Be sure that this adjustment is made after performing  P. 6-31"6.2.1 Automatic gamma
adjustment".
<Procedure>
(1) While pressing [0] and [5] simultaneously, turn the power ON.
(2) Key in a code and press the [START] button.
(3) Key in an adjustment value.
(To correct the value once keyed in, press the [CLEAR] button.)
(4) Press the [OK] or [INTERRUPT] button to store the value.  The equipment goes back to the
ready state.
(5) Press the [FAX] button and then press the [START] button to make a test copy.
(6) If the desired image quality has not been attained, repeat step (2) to (5).
Original mode
Item to be
adjusted
Remarks
Mono
color
Text/
Text
Printed
Photo Map
Black
mode
Gray
scale
-Photo- -
Adjustment
code
7727 7728 7729 7730 7731 center value The larger the value is, the
darker the image becomes.
Acceptable values:
0 to 255 (Default: 128)
Color
mode
Original mode
Item to be
adjusted
Remarks
Text/Photo Text
Custom
mode
Black 7114 7115 7258 Manual density
mode center value
The larger the value is, the darker
the image becomes.
Acceptable values:
0 to 255 (Default: 128)
7120 7121 7264 Manual density
mode dark step
value
The larger the value is, the darker
the dark side becomes.
Acceptable values:
0 to 255 (Default: 20)
7117 7118 7261 Manual density
mode light step
value
The larger the value is, the lighter
the light side becomes.
Acceptable values:
0 to 255 (Default: 20)
7123 7124 7267 Automatic density
mode
The larger the value is, the darker
the image becomes.
Acceptable values:
0 to 255 (Default: 128)
