OUTLINE OF THE MACHINE
3 - 96
[ 3 ] Heat pipe roller
A heat pipe roller consists of a cylindrical pipe containing pure water and is sealed.
Fig. 3-56
[1] Heart pipe
[2] Liquid (Water)
When external heat is applied to the heat pipe roller, the internal water evaporates. This can make the
temperature of the whole roller even in a short time.
Notes:
• Store the heat pipe roller horizontally.
• When disposing of the heat pipe, make a hole in it and pour out the water inside, otherwise it
could burst.
[1]
[2]
