e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 98
8.3.11 Paper jam in puncher unit
[E9F0] Punching jam
8.3.12 Other paper jam
[EAD0] Print end command time-out jam
Replace parts Remarks
Feeding sensor (S22)
Junction box paper detection sensor
(S26)
Transport path-2 (S27)
Transport path-3 (S28)
Ejecting roller (S29)
Interface PC board (I/F)
Saddle stitcher controller board
Finisher controller board
Classification Error item
Finisher jam
(Punch unit)
[MJ-6102]
Check item Measures
Finisher, saddle stitcher • Check if there is any paper in the finisher, punch unit or
the on the transport path of the equipment. Remove it if
there is.
Punch HP sensor (S4) • Sensor check
• Connector check
• Harness check
Punch motor (M3) • Motor check
• Connector check
• Harness check
Punch controller board • Connector check
• Board check
Replace parts Remarks
Punch HP sensor (S4)
Punch motor (M3)
Punch controller board
Classification Error item
Other paper jam The printing has not finished normally because of an error
occurring on the interface between the SYS board and the
engine firmware at the end of printing.
To Next Page
