3
© 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
OUTLINE OF THE MACHINE
3 - 29
M21 Sub-hopper toner motor-M Normal rotation:
Toner supply from the M sub-hopper to
the M developer unit and mixing toner
in the M sub-hopper
Reverse rotation:
Mixing toner in the M sub-hopper
Fig. 3-11 60-13
M22 Sub-hopper toner motor-Y Normal rotation:
Toner supply from the Y sub-hopper to
the Y developer unit and mixing toner
in the Y sub-hopper
Reverse rotation:
Mixing toner in the Y sub-hopper
Fig. 3-11 60-13
M23 Needle electrode cleaner motor-K Driving the needle electrode cleaner-K Fig. 3-11 59-11
M24 Needle electrode cleaner motor-C Driving the needle electrode cleaner-C Fig. 3-11 59-11
M25 Needle electrode cleaner motor-M Driving the needle electrode cleaner-M Fig. 3-11 59-11
M26 Needle electrode cleaner motor-Y Driving the needle electrode cleaner-Y Fig. 3-11 59-11
M27 Drum motor-K Driving the K drum Fig. 3-9 56-3
M28 Drum motor-YMC Driving the Y, M and C drums Fig. 3-9 56-2
M29 Developer unit motor-K Driving the K developer sleeve
(magnetic roller) and toner recovery
auger
Fig. 3-9 55-21
M30 Developer unit mixer motor-K Mixing the K developer material Fig. 3-9 55-20
M31 Developer unit motor-YMC Driving the Y, M and C developer
sleeve (magnetic roller) and toner
recovery auger
Fig. 3-9 55-22
M32 Developer unit mixer motor-YMC Mixing the Y, M and C developer
materials
Fig. 3-9 55-21
M33 Waste toner transport motor Transporting waste toner Fig. 3-15 65-37
M34 Polygonal motor Driving the polygonal mirror Fig. 3-14 48-1
M35 Mirror motor-M Adjusting the irradiation angle of the M
laser
Fig. 3-14 48-1
M36 Mirror motor-C Adjusting the irradiation angle of the C
laser
Fig. 3-14 48-1
M37 Mirror motor-K Adjusting the irradiation angle of the K
laser
Fig. 3-14 48-1
M38 Shutter motor Driving the laser emission outlet (slit
glass) protective shutter
Fig. 3-14 48-1
M39 Registration motor Driving the registration roller Fig. 3-13 10-22
M40 Transport motor-1 Driving the intermediate transport
roller-1
Fig. 3-19 8-3
M41 Transport motor-2 Driving the intermediate transport
roller-2
Fig. 3-19 8-3
M42 Feed motor Driving the feed roller and pickup roller
of the 1st and 2nd drawers
Fig. 3-19 8-3
M43 Feed/transport motor Driving the feed roller and the transport
roller of the 3rd and 4th drawers
Fig. 3-19 9-50
M44 Tray-up motor-1 Lifting up the trays in the 1st and 2nd
drawers
Fig. 3-19 66-7
M45 Tray-up motor-2 Lifting up the trays in the 3rd and 4th
drawers
Fig. 3-19 66-7
M46 Tandem LCF tray-up motor Lifting up the tray in the tandem LCF Fig. 3-21 12-19
M47 Tandem LCF end fence motor Driving the end fence in the tandem
LCF
Fig. 3-21 12-19
M48 2nd transfer cam motor Driving the contacting/releasing
operation of the 2nd transfer roller
Fig. 3-13 28-50
Symbol Name Function Remarks P-I
