e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved
OUTLINE OF THE MACHINE
3 - 30
3.3.2 Fans
Symbol Name Function Remarks P-I
FR1 RADF cooling fan Cools off the RADF drive section. Fig. 3-4 89-16
F1 SLG board cooling fan Cooling down the SLG board Fig. 3-5 54-28
F2 Exposure lamp cooling fan-1 Cooling down the exposure lamp Fig. 3-5 50-25
F3 Scanner unit cooling fan-1 Cooling down the scanner unit Fig. 3-5 50-15
F5 Exit paper cooling fan (front) Cooling down the exiting/reversed
paper and scanner unit, and avoiding
exposure to water
Fig. 3-6 49-56
F6 Bridge unit cooling fan (front) Cooling down the exiting/reversed
paper and scanner unit, and avoiding
exposure to water
Fig. 3-6 44-62
F7 Bridge unit cooling fan (rear) Cooling down the exiting/reversed
paper, scanner unit, bridge unit
transport motor and reverse motor, and
avoiding exposure to water
Fig. 3-6 45-66
F8 IH board cooling fan-1 Cooling down the IH board Fig. 3-8 38-29
F9 IH board cooling fan-2 Cooling down the IH board Fig. 3-8 38-29
F11 Reversed paper cooling fan Cooling down the reversed paper Fig. 3-16 18-26
F14 EPU cooling fan Cooling down the developer unit (EPU) Fig. 3-24 49-27
F15 Exit paper cooling fan (rear) Cooling down the exiting/reversed
paper and scanner unit, and avoiding
exposure to water
Fig. 3-7 49-43
F17 Main charger blowing fan-K Preventing the main charger unit-K
from being stained
Fig. 3-11 59-2
F18 Main charger blowing fan-C Preventing the main charger unit-C
from being stained
Fig. 3-11 59-2
F19 Main charger blowing fan-M Preventing the main charger unit-M
from being stained
Fig. 3-11 59-2
F20 Main charger blowing fan-Y Preventing the main charger unit-Y
from being stained
Fig. 3-11 59-3
F21 Toner cartridge heat insulation fan Insulating and cooling down the toner
cartridge
Fig. 3-7 49-48
F22 Laser optical unit cooling fan (Front) Cooling down the laser optical unit Fig. 3-14 48-8
F23 Laser optical unit cooling fan (Rear) Cooling down the laser optical unit,
transport motor and feed motor
Fig. 3-14 49-21
F24 Ozone suctioning fan Suctioning ozone generated at
charging
Fig. 3-24 49-2
F25 Scattered toner suctioning fan Suctioning toner scattering from the
developer sleeve
Fig. 3-24 49-7
F26 Exposure lamp cooling fan-2 Cooling down the exposure lamp Fig. 3-5 50-25
F27 SYS board cooling fan Cooling down the SYS board Fig. 3-22 68-9
F28 HDD cooling fan Cooling down the hard disk
(e-STUDIO5540C/6540C/6550C only)
Fig. 3-22 68-8
F29 Upper exhaust fan (left) Exhausting the heat inside (upper) the
equipment
Fig. 3-24 49-101
F30 Upper exhaust fan (right) Fig. 3-24 49-101
F31 Toner cooling exhaust fan Exhausting the heat inside the
equipment so as not to conduct it to the
toner
Fig. 3-24 47-29
F32 Upper exit section cooling fan-1 Cooling the paper which exits in the
upper exit section
Fig. 3-24 36-101
F33 Upper exit section cooling fan-2 Fig. 3-24 36-101
F34 Lower exit section cooling fan-1 Cooling the paper which exits in the
lower exit section
Fig. 3-24 35-45
F35 Lower exit section cooling fan-2 Fig. 3-24 35-45
F36 Lower exit section cooling fan-3 Fig. 3-24 49-60
