OUTLINE OF THE MACHINE

3 - 9

Fig. 3-8

IH-COIL

LAMP

Center heater lamp,

Side heater lamp,

Sub heater lamp

(for e-STUDIO5540C

/6540C/6550C

MJC, MJD)
