6
© 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
SETTING ADJUSTMENT
6 - 53
Notes:
• Be sure that this adjustment be made after performing P. 6-49"6.3.1 Automatic gamma
adjustment".
• Changing the adjustment setting influences the adjacent density area slightly.
E.g.: When the value of the medium density is larger, the adjacent areas in the low density and
high density range will become slightly darker.
• The adjustment item can be changed by the setting value of code 05-8066; however, the
maximum density may not appear as high even when High density / Maximum density is set to
high if “1” is set for “05-8066”.
<Procedure>
(1) While pressing [0] and [5] simultaneously, turn the power ON.
(2) Key in the codes to be adjusted (language and screen) and press the [START] button.
(3) Key in the value corresponding to the density area to be adjusted (0, 1 or 2) and press the
[START] button.
0: Low density 1: Medium density 2: High density/Max density
(4) Key in the adjustment value. (To correct the value once keyed in, press the [CLEAR] button.)
(5) Press the [OK] or [INTERRUPT] button to store the value in memory. The equipment goes
back to the ready state.
(6) For resetting the value, repeat step (2) to (5).
(7) Let the equipment restart and perform the printing job.
(8) If the image density has not been attained, repeat step (1) to (7)
Color
mode
Auto (PS) Auto (PCL)
Item to be
adjusted
Remarks
Text
Graphi
cs
Image Text
Graphi
cs
When
“0” is
set for
“05-
8066”
When
“1” is
set for
“05-
8066”
Black
(600dpi)
7360-0 7361-0 7362-0 7363-0 7364-0
7365
-0
Low
density
Low
density
The larger
the value is,
the density
of the item to
be adjusted
becomes
darker.
Acceptable
values: 0 to
255
(Default:
128)
7360-1 7361-1 7362-1 7363-1 7364-1
7365-
1
Medium
density
Medium
density
7360-2 7361-2 7362-2 7363-2 7364-2
7365-
2
High
density
High
density /
Maximu
m
density
Color
mode
Auto (XPS) Item to be adjusted
Remarks
Text
Graphi
cs
When “0”
is set for
“05-
8066”
When “1”
is set for
“05-
8066”
Black
(600dpi)
7366-0 7367-0 7368-0 Low
density
Low
density
The larger the value is, the density
of the item to be adjusted becomes
darker.
Acceptable values: 0 to 255
(Default: 128)
7366-1 7367-1 7368-1 Medium
density
Medium
density
7366-2 7367-2 7368-2 High
density
High
density /
Maximum
density
To Next Page
