6
© 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
SETTING ADJUSTMENT
6 - 69
6.3.20 Beam level conversion setting
The beam level used for smoothing process (divided into 4) in the BOX printing, list printing, network
FAX and e-mail FAX can be set.
The size of the dots can be adjusted.
<Adjustment Mode (05)>
Make a test copy and compare the image obtained with the current settings; if necessary, make
adjustments according to the following procedure.
<Procedure>
The procedure is the same as that of P. 6-52"6.3.2 Gamma balance adjustment (Black Mode)".
Notes:
1. The setting value must increase as the beam level number (0 to 4) becomes higher. Do not
increase this order when setting the values.
2. Usually, beam level 4 / 4 is most effective on black mode.
3. It is not applied to the images printed in the Black mode (600 dpi/1200 dpi) by the printer
driver.
Code Item to be adjusted Remarks
7300-0 Beam level 0/4 The smaller the value is, the smaller the beam width
of the primary scanning direction becomes.
Therefore, the smaller dots are reproduced
accordingly.
Acceptable values: 0 to 255
(Default: Level 0/4: 0, Level 1/4: 63, Level 2/4: 127,
Level 3/4: 191, Level 4/4: 255)
7300-1 Beam level 1/4
7300-2 Beam level 2/4
7300-3 Beam level 3/4
7300-4 Beam level 4/4
To Next Page
