e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 80
[E724] Stop jam at the original registration sensor
[E726] Transport/exit signal reception jam during ADF standby status
[E727] Jam not reaching the original reading end sensor
Replace parts Remarks
Original exit sensor
RADF board Perform the 05-3210
Roller Read roller
Classification Error item
RADF jam The trailing edge of the original does not pass the original
registration sensor after its leading edge has reached this
sensor.
Check item Measures
Registration roller • Cleaning
Original registration sensor • Sensor check
(Perform the input check: 03-[FAX]ON/[7]/[H])
• Connector check
• Harness check
RADF board • Connector check (CN74)
• Board check
Drive unit, Rollers • Gear check
• Roller check
Replace parts Remarks
Original registration sensor
RADF board Perform the 05-3210
Roller Registration roller
Classification Error item
RADF jam
Check item Measures
RADF • Check if there is any paper in the RADF. Remove it if there
is.
Equipment • Check if there is any paper in the equipment. Remove it if
there is.
• If a jam still occurs, turn the power OFF and then back ON
to check if the equipment operates normally.
Classification Error item
RADF jam
