e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 82
[E744] Stop jam at the original exit/reverse sensor
[E745] Jam not reaching the original exit reverse sensor
Check item Measures
Exit roller • Cleaning
Original exit sensor • Sensor check
(Perform the input check: 03-[FAX]ON/[7]/[E])
• Connector check
• Harness check
RADF board • Connector check (CN75)
• Board check
Drive unit, Rollers • Gear check
• Roller check
Replace parts Remarks
Original exit sensor
RADF board Perform the 05-3210
Roller Exit roller
Classification Error item
RADF jam The trailing edge of the original does not pass the original
exit/reverse sensor after its leading edge has reached this
sensor.
Check item Measures
Intermediate transport roller • Cleaning
Original exit/reverse sensor • Sensor check
(Perform the input check: 03: [FAX]/ON/[5]/[B])
• Connector check
• Harness check
RADF board • Connector check (CN75)
• Board check
Drive unit, Rollers • Gear check
• Roller check
Replace parts Remarks
Original exit/reverse sensor
RADF board Perform the 05-3210
Roller Intermediate transport roller
Classification Error item
RADF jam
Check item Measures
Intermediate transport roller • Cleaning
To Next Page
