ERROR CODE and TROUBLESHOOTING
8 - 96
[EAA0] Power-ON jam
[EAB0] Paper transport stop jam
Classification Error item
Finisher jam
(Saddle stitcher section)
Paper exists at No.1 paper sensor, No. 2 paper sensor, No.3
paper sensor, vertical path paper sensor or delivery sensor
when power is turned ON. [MJ-1104]
Check item Measures
Finisher, saddle stitcher • Check if there is any paper in the finisher, saddle stitcher
or the on the transport path of the equipment. Remove it if
there is.
No. 1 paper sensor (PI18) • Sensor check
• Connector check
• Harness check
No. 2 paper sensor (PI19) • Sensor check
• Connector check
• Harness check
No. 3 paper sensor (PI20) • Sensor check
• Connector check
• Harness check
Vertical path paper sensor (PI17) • Sensor check
• Connector check
• Harness check
Delivery sensor (PI11) • Sensor check
• Connector check
• Harness check
Saddle stitcher controller board • Connector check(J10, J13)
• Board check
Replace parts Remarks
No. 1 paper sensor (PI18)
No. 2 paper sensor (PI19)
No. 3 paper sensor (PI20)
Vertical path paper sensor (PI17)
Delivery sensor (PI11)
Saddle stitcher controller board
Classification Error item
Finisher jam
(Saddle stitcher section)
The paper which passed through the inlet sensor does not
reach or pass No.1 paper sensor, No. 2 paper sensor, No.3
paper sensor or delivery sensor. [MJ-1104]
Check item Measures
Finisher, saddle stitcher • Check if there is any paper in the finisher, saddle stitcher
or the on the transport path of the equipment. Remove it if
there is.
No. 1 paper sensor (PI18) • Sensor check
• Connector check
• Harness check
