ERROR CODE and TROUBLESHOOTING
8 - 128
[C560] Communication error between Engine-CPU and PFC board
[C570] Communication error between Engine-CPU and CNV-CPU
[C580] Communication error between CNV-CPU and finisher
Replace parts Remarks
RADF board Replace the RADF board, and then perform the automatic
adjustment for the original reading start sensor (05-3210).
SLG board
Classification Error item
Optional communication related
service call
Check item Measures
PFC board • Connector check (CN500, CN501)
• Harness check
• Board check
LGC board • Connector check (CN301, CN303)
• Board check
Replace parts Remarks
PFC board
LGC board
Classification Error item
Optional communication related
service call
Check item Measures
Harness (MFP - Finisher) • Connector check
• Harness check
LGC board • Connector check (CN332)
• Board check
Replace parts Remarks
LGC board
Classification Error item
Optional communication related
service call
Check item Measures
Finisher • Check if the specified finisher is attached.
LGC board • Connector check
• Board check

Toshiba e-STUDIO 6550C e-STUDIO 5560C Specifications

General

Category	All in One Printer
Print Speed (Color)	55 ppm
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Paper Capacity	3, 700 sheets
Maximum Paper Size	A3
Type	Color
Scan Resolution	600 dpi
Connectivity	USB, Ethernet
Supported Paper Sizes	A4, A5, B5
