April 2017
6-51
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
General Procedures and Information
Launch Issue
Input Codes
Table 1 Input codes 005
Code Displayed Name Description General
005-102 Document Sensor Document sensor (Q05-102) High = document
present
005-110 Regi Sensor Registration sensor (Q05-110) High = no docu-
ment
005-206 CVT Pre Regi Sensor Pre-registration sensor (Q05-206) High = no docu-
ment
005-211 CVT Invert Sensor Invert sensor (Q05-211) High = no docu-
ment
005-212 CVT Feeder Cover
Interlock Switch
CVT feeder cover sensor (Q05-212) High = Cover
closed
005-213 CVT DADF Interlock
Switch
CVT DADF interlock switch (S05-
213)
High = DADF low-
ered
005-215 CVT #1 Tray APS Sen-
sor (CVT)
Tray APS sensor 1 (Q05-215) High/Low
005-216 CVT #2 Tray APS Sen-
sor (CVT)
Tray APS sensor 2 (Q05-216) High/Low
005-217 CVT #3 Tray APS Sen-
sor (CVT)
Tray APS sensor 3 (Q05-217) High/Low
005-218 CVT APS No. 1 Sensor APS sensor 1 (Q05-218) Low = document
present
005-219 CVT APS No. 2 Sensor APS sensor 2 (Q05-219) Low = document
present
005-220 CVT APS No. 3 Sensor APS sensor 3 (Q05-220) Low = document
present
005-221 CVT Tray Size SNR No.
1
Tray size sensor 1 (Q05-221) Low = document
present
005-222 CVT Tray Size SNR No.
2
Tray size sensor 2 (Q05-222) Low = document
present
005-224 Scan Start (CVT) Scan count signal. High = on
005-226 #2 Invert Sensor (PF1) Invert sensor 2 (Q05-226) Low = document
present
005-234 Home Position SNR Link home position sensor (Q05-
234) for nip release
High = nip closed
Table 2 Input Codes 012 - Integrated Office Finisher
Code Displayed Name Description General
012-111 IOT Exit Sensor IOT exit sensor (Q12-111) High/Low
012-140 Ent Sensor Entry sensor (Q12-140) High/Low
012-150 Compile Exit Sensor Compiler exit sensor (Q12-150) High/Low
012-220 Front Tamper Home
Sensor
Front tamper home sensor (Q12-
220)
High = home
012-221 Rear Tamper Home
Sensor
Rear tamper home sensor (Q12-
221)
High = home
012-242 Low Staple Sensor Low staples sensor (Q12-242) High = almost
empty
012-243 Self Priming Sensor Self priming sensor (Q12-243) High = ready
012-244 Staple Home Sensor Staple head home sensor (Q12-244) High = staple head
home
012-251 Set Clamp Home Sen-
sor
Set clamp home sensor (Q12-251) High = set clamp
home
012-252 Eject Home Sensor Ejector home sensor (Q12-252) High = Ejector
home
012-267 Stack Height Sensor Stack height sensor (Q12-267) High/Low
012-278 Stack Sensor1 Stack sensor 1 (Q12-278) High/Low
012-279 Stack Sensor2 Stack sensor 2 (Q12-279) High/Low
012-300 Top Cover Interlock Top cover interlock switch (S12-302) High/Low
012-302 Finisher Front Door SW Font door interlock switch (S12-302) High/Low
Table 3 Input Codes 012 and 013 - Office Finisher LX
Code Displayed Name Description General
012-100 Transport Entrance
Sensor
Transport entry sensor (Q12-100) High/Low
012-110 Reg. Clutch on Detect Registration clutch (CL12-110) On/off
012-111 IOT Exit Sensor IOT exit sensor (Q12-111) High/Low
012-150 Compile Exit Sensor Compiler exit sensor (Q12-150) High/Low
012-151 Compiler Tray No Paper
Sensor
Compiler tray no paper sensor (Q12-
151)
High/Low
012-190 H-Transport Entrance
Sensor
H-transport entrance sensor (Q12-
190)
High/Low
012-220 Front Tamper Home
Sensor
Front tamper home sensor (Q12-
220)
High = home
012-221 Rear Tamper Home
Sensor
Rear tamper home sensor (Q12-
221)
High = home
012-241 Stapler Move Position
Sensor
Stapler move position sensor (Q12-
241)
High/Low
012-242 Low Staple Sensor Low staples sensor (Q12-242) High = almost
empty
012-243 Self Priming Sensor Self priming sensor (Q12-243) High = ready
012-244 Staple Home Sensor Staple head home sensor (Q12-244) High = staple head
home
012-250 Eject Clamp Home Sen-
sor
Eject clamp home sensor (Q12-250) High/Low
012-251 Set Clamp Home Sen-
sor
Set clamp home sensor (Q12-251) High = set clamp
home
Table 2 Input Codes 012 - Integrated Office Finisher
Code Displayed Name Description General
To Next Page
