Xerox VersaLink B7025 Service Manual

April 2017
6-52
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
Launch Issue
General Procedures and Information
012-260 Upper Limit Sensor Upper limit sensor (Q12-260) High/Low
012-262 Stacker Paper Sensor Stacker paper sensor (Q12-262) High/Low
012-263 Stacker Encoder Sensor Stacker encoder sensor (Q12-263) High/Low
012-264 Stack Height Sensor 1 Stack height sensor 1 (Q12-264) High/Low
012-265 Stack Height Sensor 2 Stack height sensor 2 (Q12-265) High/Low
012-271 Punch Home Sensor Punch home sensor (Q12-271) High/Low
012-274 Punch Encoder Sensor Punch encoder sensor (Q12-274) High/Low
012-275 Punch Box Set Sensor Punch box set sensor (Q12-275) High/Low
012-277 Puncher Detect Puncher detect (Q12-277) High/Low
012-300 Eject Cover Switch Eject cover switch (S12-300) High/Low
012-302 Fin. Front Door Intlk
Switch
Finisher front door interlock switch
(S12-302)
High/Low
012-303 H-Transport Open Sen-
sor
H-transport open sensor (Q12-303) High/Low
013-101 Folder Home Sensor Folder home sensor (Q13-101) High/Low
013-107 Booklet Front Low Sta-
ple Switch
Booklet front low staple switch (S13-
107)
High = Staple slow
013-108 Booklet Rear Low Sta-
ple Switch
Booklet rear low staple switch (S13-
108)
High = Staple slow
013-141 Booklet Front Staple
Home Switch
Booklet front staple home switch
(S13-141)
High/Low
013-142 Booklet Rear Staple
Home Switch
Booklet rear staple home switch
(S12-142)
High/Low
013-143 Booklet Stapler Move
Position Sensor
Booklet stapler move position sen-
sor (S13-143)
High/Low
013-144 Booklet Stapler Move
Home Sensor
Booklet stapler move home sensor
(S13-144)
High/Low
013-160 Folder Detect Folder detect High/Low
013-161 Booklet Detect Booklet detect High/Low
013-300 Booklet Cover Open
Switch
Booklet cover open switch (S13-
300)
High/Low
013-301 Booklet Safety Switch Booklet safety switches High/Low
Table 4 Input codes 042
Code Displayed Name Description General
042-250 Fusing Exhaust Fan Fail Detects using exhaust fan fail. -
042-251 Marking Fan FAIL Detects marking fan fail. -
Table 5 Input codes 062
Code Displayed Name Description General
062-212 IIT Regi Sensor Scanner registration sensor (Q62-
212)
Low = Actuated
Table 3 Input Codes 012 and 013 - Office Finisher LX
Code Displayed Name Description General
062-240 ADF Exist DADF present sensor (Q62-240) High = DADF pres-
ent
062-251 APS Sensor1 APS sensor 1 (Q62-251) High = document
present
062-253 APS Sensor3 APS sensor 3(Q62-253) High = document
present
062-300 Platen I/L Switch Platen I/L sensor (Q62-300) Low = DADF
closed
062-301 Angle Sensor Angle sensor (Q62-301) Low = DADF
closed
Table 6 Input codes 071 to 078
Code Displayed Name Description General
071-101 #1 No Paper Sensor Tray 1 no paper sensor (Q71-101) High = Paper
empty
071-102 #1 Level Sensor Tray 1 level sensor (Q71-102) High = top of stack
sensed
071-104 #1 Tray Paper Size
Switch
Tray 1 paper size switch (S71-104) High = Tray out
071-105 #1 Pre Feed Sensor Tray 1 pre feed sensor (Q71-105) High = paper
detected
072-101 #2 No Paper Sensor Tray 2 no paper sensor (Q72-101) High = Paper
empty
072-102 #2 Level Sensor Tray 2 level sensor (Q72-102) High = top of stack
sensed
072-103 #2 Feed Out Sensor Tray 2 feed out sensor (Q72-103) High = Paper
Detected
072-104 #2 Tray Paper Size Sen-
sor Digital
Tray 2 paper size sensor (Q72-104) High/Low
073-101 #3 No Paper Sensor Tray 3 no paper sensor (Q73-101) High = Paper
empty
073-102 #3 Level Sensor Tray 3 level sensor (Q73-102) High = top of stack
sensed
073-103 #3 Feed Out Sensor Tray 3 feed out sensor (Q73-103) High = Paper
Detected
073-104 #3 Tray Paper Size Sen-
sor Digital
Tray 3 paper size sensor (Q73-104) High/Low
074-101 #4 No Paper Sensor Tray 4 no paper sensor (Q74-101) High = Paper
empty
074-102 #4 Level Sensor Tray 4 level sensor (Q74-102) High = top of stack
sensed
074-103 #4 Feed Out Sensor Tray 4 feed out sensor (Q74-103) High = Paper
Detected
Table 5 Input codes 062
Code Displayed Name Description General

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
