April 2017
6-53
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
General Procedures and Information
Launch Issue
Output Codes
074-104 #4 Tray Paper Size Sen-
sor Digital
Tray 4 paper size sensor (Q74-104) High/Low
075-100 MSI No Paper Sensor Bypass tray no paper sensor (Q75-
100)
High = Paper
detected
077-100 #2 Exit Sensor Exit 2 sensor (Q77-100) High = paper
detected
077-101 #1 Exit Sensor Exit 1 sensor (Q77-101) High = paper
detected
077-104 Regi Sensor Registration sensor (Q77-104) High = paper
detected
077-105 #2 Feed Out Sensor #2 Feed Out Sensor High = paper
detected
077-120 IOT Feed Ready Signal
Input
Feed ready signal On/off
077-121 Tray Module Regi Stop
Signal Input
Registration stop signal. On/off
077-123 Tray Module Feed ON
Signal Input
Feed on signal. On/off
077-124 #1 OCT Full Stack Sen-
sor
Exit 1 OCT full stack sensor (Q77-
124)
High/Low
077-300 Left Hand Interlock
Switch
Left hand interlock switch (S77-300) High/Low
077-302 Left Hand High Cover
Switch
Left hand high cover switch (S77-
302)
High/Low
077-303 Front Interlock Switch Front interlock switch (S77-303) High/Low
077-306 Tray Module Left Hand
Interlock Switch
TM left hand interlock switch (S77-
306)
High = cover
closed
078-100 HCF1 Pre Feed Sensor HCF pre feed sensor (Q78-100) High/Low
078-101 HCF1 Feed Out Sensor HCF feed out sensor (Q78-101) High/Low
078-200 HCF1 No Paper Sensor HCF no paper sensor (Q78-200) High/Low
078-201 HCF1 Level Sensor HCF level sensor (Q78-201) High/Low
078-202 HCF1 Size Sensor A HCF size sensor A (Q78-202) High/Low
078-203 HCF1 Size Sensor B HCF size sensor B (Q78-203) High/Low
078-204 HCF1 Tray In Sensor HCF tray in sensor (Q78-204) High/Low
078-300 HCF1 Transport Inter-
lock
HCF transport interlock(S78-300) High/Low
078-301 HCF1 Side Out Switch HCF side out switch (S78-301) High/Low
Table 6 Input codes 071 to 078
Code Displayed Name Description General
Table 7 Output Codes 005
Code Displayed Name Description General
005-004 Feed Motor (CCW)
82.5mm/s
Runs the DADF feed motor
(MOT05-004) counter clockwise at
82.5mm/s. 50 seconds timeout.
On/off
005-005 Feed Motor (CCW)
110.0mm/s
Runs the DADF feed motor
(MOT05-004) counter clockwise at
110mm/s. 50 seconds timeout.
On/off
005-008 Feed Motor (CCW)
165.0mm/s
Runs the DADF feed motor
(MOT05-004) counter clockwise at
165mm/s. 50 seconds timeout.
On/off
005-009 Feed Motor (CW)
330.0mm/s
Runs the DADF feed motor
(MOT05-004) clockwise at 330mm/
s. 50 second timeout.
On/off
005-010 Feed Motor (CCW)
220.0mm/s
Runs the DADF feed motor
(MOT05-004) counter clockwise at
220mm/s. 50 second timeout.
On/off
005-013 Feed Motor (CW)
440.0mm/s
Runs the DADF feed motor
(MOT05-004) clockwise at 440mm/
s. 50 second timeout.
On/off
005-015 Feed Motor (CCW)
330.0mm/s
Runs the DADF feed motor
(MOT05-004) counter clockwise at
330mm/s. 50 second timeout.
On/off
005-047 Feed Motor (CW)
110.0mm/s
Runs the DADF feed motor
(MOT05-004) clockwise at 110mm/
s. 50 second timeout.
On/off
005-048 Feed Motor (CW)
165.0mm/s
Runs the DADF feed motor
(MOT05-004) clockwise at 165mm/
s. 50 second timeout.
On/off
005-049 Feed Motor (CW)
220.0mm/s
Runs the DADF feed motor
(MOT05-004) clockwise at 220mm/
s. 50 second timeout.
On/off
005-062 DADF Feed Clutch Energises the DADF feed clutch
(CL05-062). 50 second timeout.
On/off
005-072 Nip Release Solenoid Nip release solenoid (SOL05-072). 3
second timeout.
On/off
005-083 Doc Ready Switches on the document ready
signal.
On/off
005-088 Image Area Image area On/off
005-098 Takeaway Clutch Energises the DADF takeaway
clutch (CL05-098). 50 second time
-
out.
On/off
