Xerox VersaLink B7025 Service Manual

April 2017
6-54
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
Launch Issue
General Procedures and Information
Table 8 Output Codes 012 - Integrated Office Finisher
Code Displayed Name Description General
012-013 Sub Paddle Solenoid Energizes the sub paddle solenoid
(SOL12-013).
CAUTION
Do not run with 012-014. Running
these codes at the same time can
cause damage to the machine.
On/off. 660ms
timeout.
012-014 Sub Paddle Rotation Simultaneously runs the transport
motor (MOT12-095) and energizes
the paddle solenoid (SOL12-013) to
rotate the sub paddle once.
CAUTION
Do not run with 012-013, 012-095,
012-096 or 012-097. Running these
codes at the same time can cause
damage to the machine.
On/off. 660ms
timeout.
012-017 Set Clamp Motor Runs the set clamp motor (MOT12-
017).
CAUTION
Do not run with 012-061. Running
these codes at the same time can
cause damage to the machine.
On/off. 250 pulses.
012-020 Front Tamper Mot Low
Front
Runs the front tamper motor
(MOT12-020) at low speed to move
the front tamper forward.
On/off. 100 pulses.
012-021 Front Tamper Mot Mid-
dle Front
Runs the front tamper motor
(MOT12-020) at mid speed to move
the front tamper forward.
On/off. 100 pulses
012-022 Front Tamper Mot High
Front
Runs the front tamper motor
(MOT12-020) at high speed to move
the front tamper forward.
On/off. 100 pulses
012-023 Front Tamper Mot Low
Rear
Runs the front tamper motor
(MOT12-020) at low speed to move
the front tamper backward.
On/off. 100 pulses.
012-024 Front Tamper Mot Mid-
dle Rear
Runs the front tamper motor
(MOT12-020) at mid speed to move
the front tamper backward.
On/off. 100 pulses
012-025 Front Tamper Mot High
Rear
Runs the front tamper motor
(MOT12-020) at high speed to move
the front tamper backward.
On/off. 100 pulses
012-026 Rear Tamper Mot Low
Front
Runs the rear tamper motor
(MOT12-026) at low speed to move
the rear tamper forward.
On/off. 100 pulses.
012-027 Rear Tamper Mot Mid-
dle Front
Runs the rear tamper motor
(MOT12-026) at mid speed to move
the rear tamper forward.
On/off. 100 pulses
012-028 Rear Tamper Mot High
Front
Runs the rear tamper motor
(MOT12-026) at high speed to move
the rear tamper forward.
On/off. 100 pulses
012-029 Rear Tamper Mot Low
Rear
Runs the rear tamper motor
(MOT12-026) at low speed to move
the rear tamper backward.
On/off. 100 pulses.
012-030 Rear Tamper Mot Mid-
dle Rear
Runs the rear tamper motor
(MOT12-026) at mid speed to move
the rear tamper backward.
On/off. 100 pulses
012-031 Rear Tamper Mot High
Rear
Runs the rear tamper motor
(MOT12-026) at high speed to move
the rear tamper backward.
On/off. 100 pulses
012-046 Staple Motor FOR-
WARD
Runs the staple motor (MOT12-046)
forwards.
On/off.
012-047 Staple Motor REVERSE Runs the staple motor (MOT12-046)
in reverse.
On/off. 180ms
timeout.
012-054 Eject Motor Low FOR-
WARD
Runs the eject motor (MOT12-054)
at low speed to move the ejector out.
On/off. 2000 pulses
012-055 Eject Motor High FOR-
WARD
Runs the eject motor (MOT12-054)
at high speed to move the ejector
out.
On/off. 2000 pulses
012-056 Eject Motor Low
REVERSE
Runs the eject motor (MOT12-054)
at low speed to move the ejector
home.
On/off. 2000 pulses
012-057 Eject Motor High
REVERSE
Runs the eject motor (MOT12-054)
at high speed to move the ejector
home.
On/off. 2000 pulses
012-060 Stacker Motor UP Runs the stacker motor (MOT12-
060) to drive the stacker tray up.
On/Off. 80ms time-
out.
012-061 Stacker Motor DOWN Runs the stacker motor (MOT12-
060) to drive the stacker tray down.
On/Off. 80ms time-
out.
012-095 Transport Motor Low Runs the transport motor (MOT12-
095) forward at low speed (equal to
full IOT speed).
-
012-096 Transport Motor Hi Runs the transport motor (MOT12-
095) forward at high speed (trans
-
port speed in finisher).
-
012-097 Transport Motor Half
Speed
Runs the transport motor (MOT12-
095) forward at half speed (equal to
half IOT speed).
-
012-110 Registration Clutch ON Energizes the registration clutch
(CL12-110).
-
Table 8 Output Codes 012 - Integrated Office Finisher
Code Displayed Name Description General
