Xerox VersaLink B7025 Service Manual

April 2017
6-55
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
General Procedures and Information
Launch Issue
Table 9 Output Codes 012 and 013 - Office Finisher LX
Code Displayed Name Description General
012-013 Sub Paddle Solenoid Energizes the sub paddle solenoid
(SOL12-013).
On/off. 250 ms
012-018 Transport Motor
Reverse
Runs the transport motor (MOT12-
018) in reverse.
On/off.
012-020 Front Tamper Mot Low
Front
Runs the front tamper motor
(MOT12-020) at low speed to move
the front tamper forward.
On/off. 82 pulses
012-022 Front Tamper Mot High
Front
Runs the front tamper motor
(MOT12-020) at high speed to move
the front tamper forward.
On/off. 82 pulses
012-023 Front Tamper Mot Low
Rear
Runs the front tamper motor
(MOT12-020) at low speed to move
the front tamper backward.
On/off. 82 pulses
012-025 Front Tamper Mot High
Rear
Runs the front tamper motor
(MOT12-020) at high speed to move
the front tamper backward.
On/off. 82 pulses
012-026 Rear Tamper Motor Low
Front
Runs the rear tamper motor
(MOT12-026) at low speed to move
the rear tamper forward.
On/off. 82 pulses
012-028 Rear Tamper Motor
High Front
Runs the rear tamper motor
(MOT12-026) at high speed to move
the front tamper forward.
On/off. 82 pulses
012-029 Rear Tamper Motor Low
Rear
Runs the rear tamper motor
(MOT12-026) at low speed to move
the rear tamper backward.
On/off. 82 pulses
012-031 Rear Tamper Motor
High Rear
Runs the rear tamper motor
(MOT12-026) at high speed to move
the rear tamper backward.
On/off. 82 pulses
012-032 H-Transport Motor 1 Runs the horizontal transport motor
(MOT12-032) forward at highest
speed.
On/off.
012-033 H-Transport Motor 2 Runs the horizontal transport motor
(MOT12-032) forward at high speed.
On/off.
012-034 H-Transport Motor 3 Runs the horizontal transport motor
(MOT12-032) forward at mid speed.
On/off.
012-035 H-Transport Motor 4 Runs the horizontal transport motor
(MOT12-032) forward at low speed.
On/off.
012-036 Transport Motor 1 Runs the transport motor (MOT12-
036) forward at high speed.
On/off.
012-037 Transport Motor 2 Runs the transport motor (MOT12-
036) forward at mid speed.
On/off.
012-038 Transport Motor 3 Runs the transport motor (MOT12-
036) forward at low speed.
On/off.
012-039 H-Transport Motor
Reverse
Runs the horizontal transport motor
(MOT12-032) in reverse.
On/off.
012-040 Stapler Move Motor
Front Low
Runs the stapler move motor
(MOT12-040) to move the stapler
assembly to the front at low speed.
On/off.
012-042 Stapler Move Motor
Front High
Runs the stapler move motor
(MOT12-040) to move the stapler
assembly to the front at high speed.
On/off.
012-043 Stapler Move Motor
Rear Low
Runs the stapler move motor
(MOT12-040) to move the stapler
assembly to the rear at low speed.
On/off.
012-045 Stapler Move Motor
Rear High
Runs the stapler move motor
(MOT12-040) to move the stapler
assembly to the rear at high speed.
On/off.
012-046 Staple Motor Forward Runs the stapler motor (MOT12-
046) forwards.
On/off.
012-047 Staple Motor Reverse Runs the stapler motor (MOT12-
046) in reverse.
On/off. 200ms
timeout.
012-050 Set Clamp Clutch Energizes the set clamp clutch
(CL12-050).
On/off. 583 pulses.
012-052 Eject Clamp Up Runs the eject motor (MOT12-054)
in reverse at high speed to raise the
eject clamp roll.
On/off. 200ms
timeout.
012-053 Eject Clamp Down Runs the eject motor (MOT12-054)
in reverse at high speed to lower the
eject clamp roll.
On/off. 46 pulses
after home.
012-054 Eject Motor Forward
Low
Runs the eject motor (12-054) for-
ward at low speed.
On/off. 1136
pulses.
012-055 Eject Motor Forward
High
Runs the eject motor (12-054) for-
ward at high speed.
On/off. 1136
pulses.
012-060 Stacker Motor Up Runs the stacker motor (MOT12-
060) to drive the stacker tray up.
On/Off. 500ms
timeout.
012-061 Stacker Motor Down Runs the stacker motor (MOT12-
060) to drive the stacker tray down.
On/Off. 500ms
timeout.
012-074 Punch Motor Move
Home
Runs the punch motor (MOT12-074)
to drive the punch home.
On/off.
012-077 Punch (2 hole) Runs the punch motor (MOT12-074)
to drive 2 hole punch movement.
On/off.
012-078 Punch (3 hole) Runs the punch motor (MOT12-074)
to drive 3 hole punch movement.
On/off.
012-079 Punch (4 hole) Runs the punch motor (MOT12-074)
to drive 4 hole punch movement.
On/off.
013-022 Knife Motor Forward Runs the knife motor (MOT13-022)
forward.
On/off.
013-023 Knife Motor Reverse Runs the knife motor (MOT13-022)
in reverse.
On/off.
Table 9 Output Codes 012 and 013 - Office Finisher LX
Code Displayed Name Description General

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
