Xerox VersaLink B7025 Service Manual

April 2017
6-56
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
Launch Issue
General Procedures and Information
013-024 Booklet Front Stapler
Motor Forward
Runs the front booklet staple motor
(MOT13-024) forward.
On/off.
013-025 Booklet Front Stapler
Motor Reverse
Runs the front booklet staple motor
(MOT13-024) in reverse.
On/off.
013-026 Booklet Rear Stapler
Motor Forward
Runs the rear booklet staple motor
(MOT13-026) forward.
On/off.
013-027 Booklet Front Stapler
Motor Reverse
Runs the rear booklet staple motor
(MOT13-026) in reverse.
On/off.
013-028 Booklet Staple Move
Motor In
Runs the booklet staple move motor
(MOT13-028) to move booklet sta
-
pler to the I/B side.
On/off. 350 pulses
013-029 Booklet Staple Move
Motor Out
Runs the booklet staple move motor
(MOT13-028) to move booklet sta
-
pler to the O/B side.
On/off. 350 pulses
Table 10 Output Codes 042
Code Displayed Name Description General
042-001 Drum Motor (175 mm/s) Runs the drum motor (MOT42-001)
at 175mm/s (30/35ppm process
speed).
On/off
042-002 Drum Motor (126 mm/s) Runs the drum motor (MOT42-001)
at 126mm/s (25ppm process speed)
On/off
042-003 Main Motor (175 mm/s) Runs the main motor (MOT42-003)
at 175mm/s (30/35ppm process
speed).
On/off
042-004 Main Motor (126 mm/s) Runs the main motor (MOT42-003)
at 126mm/s (25ppm process
speed).
On/off
042-050 Fusing Unit Exhaust
Fan High Speed
Rotation
Runs the fuser exhaust fan (MOT42-
050) at high speed.
On/off
042-051 Fusing Unit Exhaust
Fan Low Speed
Rotation
Runs the fuser exhaust fan (MOT42-
050) at low speed.
On/off
042-052 Marking Fan High
Speed Rotation
Runs the marking fan (MOT42-052)
at high speed.
On/off
042-053 Marking Fan Low Speed
Rotation
Runs the marking fan (MOT42-052)
at low speed.
On/off
Table 11 Output Codes 061 and 062
Code Displayed Name Description General
061-001 LPH forced ON (all-
solid)
Switches on the print head assembly
(all beta pattern).
On/off
Table 9 Output Codes 012 and 013 - Office Finisher LX
Code Displayed Name Description General
061-002 LPH forced ON (Cin
50%)
Switches on the print head assembly
(Cin 50%).
On/off
061-003 LPH forced ON (thyris-
tor transfer)
Switches on the print head assembly
(performs thyristor transfer only.
On/off
062-002 IIT Exposure Lamp Switches on the exposure Lamp. 3
minute timeout.
On/off
062-005 IIT Scan Motor (Scan
direction)
Runs the scan motor (MOT62-005)
to drive the scan carriage 50mm (2
inches) in the scan direction.
-
062-006 IIT Scan Motor (Return
direction)
Runs the scan motor (MOT62-005)
to drive the scan carriage 50mm (2
inches) in the return direction.
-
Table 12 Output Codes 071 to 078
Code Displayed Name Description General
071-001 #1 Feed Motor 1-2-
phase Feed Direction
Runs the tray 1 feed/lift motor
(MOT71-001) at paper feed speed in
the feed direction.
On/off
071-002 #1 Feed Motor 2-phase
Lift Up Direction
Runs the tray 1 feed/lift motor
(MOT71-001) at tray lift speed in the
lift direction.
On/off
072-001 #2 Feed Motor 2-phase
(CW 2) Feed Direction
Runs the tray 2 feed/lift motor
(MOT72-001) at paper feed speed in
the feed direction (2 phase control).
On/off
072-002 #2 Feed Motor 2-phase
(CCW 2) Lift Up Direc
-
tion
Runs the tray 2 feed/lift motor
(MOT72-001) at tray lift speed in the
lift direction.
On/off
072-003 #2 Feed Motor 1-2-
phase (CW 1-2) Feed
Direction
Runs the tray 2 feed/lift motor
(MOT72-001) at paper feed speed in
the feed direction (1-2 phase con
-
trol)
On/off
073-001 #3 Feed Motor 2-phase
(CW 2) Feed Direction
Runs the tray 3 feed/lift motor
(MOT73-001) at paper feed speed in
the feed direction (2 phase control).
On/off
073-002 #3 Feed Motor 2-phase
(CCW 2) Lift Up Direc
-
tion
Runs the tray 3 feed/lift motor
(MOT73-001) at paper feed speed in
the feed direction (1-2 phase con
-
trol)
On/off
073-003 #3 Feed Motor 1-2-
phase (CW 1-2) Feed
Direction
Runs the tray 3 feed/lift motor
(MOT73-001) (1-2 phase control)
On/off
074-001 #4 Feed Motor 2-phase
(CW 2) Feed Direction
Runs the tray 4 feed/lift motor
(MOT74-001) at paper feed speed in
the feed direction (2 phase control).
On/off
Table 11 Output Codes 061 and 062
Code Displayed Name Description General

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
